Node-RED MQTT topic mapping is the quickest way to turn the flat, vendor-specific topics your devices already publish into a clean ISA-95 hierarchy that the rest of the plant can understand. In this tutorial you will build a small Node-RED flow that subscribes to raw device topics, looks each device up in a mapping table, normalises the payload and republishes it to a structured namespace on a ConnectMQ broker.
Why Remap MQTT Topics at All?
Most brownfield installations grow organically. A temperature gateway publishes to dev/th-0042/temp, a power meter uses meter7/kw, and a PLC gateway writes plc/line2/status. Each topic made sense to whoever configured that device, but together they tell a consumer nothing about where the data lives in the plant.
A Unified Namespace fixes this by agreeing on one hierarchy, typically following ISA-95 levels: enterprise, site, area, line, cell or machine, and finally the data point. When every message sits at a predictable path such as acme/izmir/packaging/line2/filler1/temperature, dashboards, historians and analytics tools can subscribe with wildcards instead of maintaining a long list of exceptions. The background on this pattern is covered in our guide to Sparkplug B and the Unified Namespace.
You often cannot reconfigure the devices themselves. Firmware may be locked, the vendor may be gone, or touching a production controller requires a change window you will not get this quarter. Node-RED sits in the middle and does the translation without touching the source.
Designing the Target ISA-95 Topic Structure
Decide the target structure before writing any code. A mapping flow is only as good as the namespace it writes into. A practical layout looks like this:
| Level | Example value | Notes |
|---|---|---|
| Enterprise | acme | Often implied by the broker or a fixed prefix |
| Site | izmir | One per physical plant |
| Area | packaging | Department or hall |
| Line | line2 | Production line or process unit |
| Machine | filler1 | Cell, machine or asset |
| Data point | temperature | One measurement or state per topic |
A few rules keep the namespace healthy over time:
- Use lowercase, ASCII and no spaces, so topics are easy to type in subscriptions and filters.
- Publish one data point per topic, or one well-defined JSON object per machine, and keep the choice consistent.
- Never put timestamps, sequence numbers or values into the topic itself.
- Keep depth under control. On the public MQTT test broker at broker.connectmq.com a topic can have at most 8 levels, so this tutorial uses a three-level demo prefix plus five ISA-95 levels.
For the demo we will use connectmq/demo/ab12cd as the prefix (replace ab12cd with your own random string), raw input under connectmq/demo/ab12cd/raw/#, and structured output as connectmq/demo/ab12cd/<site>/<area>/<line>/<machine>/<point>. Remember that the public area is readable by everyone, so only send test data there.
How Node-RED MQTT Topic Mapping Works
The flow has four parts:
- An mqtt in node subscribes to the raw topics with a wildcard.
- A function node splits the incoming topic, finds the device in a lookup table, builds the new topic and normalises the payload.
- An mqtt out node publishes the result. If its own topic field is empty, it uses
msg.topic, which is exactly what we want. - A second output of the function node sends unmapped messages to a debug node so you can spot new or misconfigured devices.
If you are new to the MQTT nodes themselves, start with the Node-RED MQTT tutorial and come back here.
The mapping table
Keep the mapping in one place. For a handful of devices a JavaScript object inside the function node is fine. For dozens, load it from a file or a retained MQTT message into global context so you can update it without redeploying.
The function node
Paste this into a function node and set it to 2 outputs:
// Raw topics look like: connectmq/demo/ab12cd/raw/<deviceId>/<rawPoint>
const PREFIX = "connectmq/demo/ab12cd";
// deviceId -> ISA-95 location
const devices = {
"th-0042": { site: "izmir", area: "packaging", line: "line2", machine: "filler1" },
"meter7": { site: "izmir", area: "utilities", line: "main", machine: "meter7" },
"plc-l2": { site: "izmir", area: "packaging", line: "line2", machine: "plc" }
};
// raw point name -> normalised point name and unit
const points = {
"temp": { name: "temperature", unit: "C" },
"hum": { name: "humidity", unit: "%" },
"kw": { name: "power", unit: "kW" },
"status": { name: "state", unit: null }
};
const parts = msg.topic.split("/");
// parts: [connectmq, demo, ab12cd, raw, deviceId, rawPoint]
const deviceId = parts[4];
const rawPoint = parts[5];
const loc = devices[deviceId];
const point = points[rawPoint];
if (!loc || !point || parts.length !== 6) {
node.warn("Unmapped topic: " + msg.topic);
return [null, msg];
}
// Accept plain numbers, strings or JSON objects with a "value" field
let value = msg.payload;
if (typeof value === "object" && value !== null && "value" in value) {
value = value.value;
}
const numeric = Number(value);
const out = {
topic: [PREFIX, loc.site, loc.area, loc.line, loc.machine, point.name].join("/"),
payload: {
value: isNaN(numeric) ? value : numeric,
unit: point.unit,
ts: new Date().toISOString(),
source: msg.topic
},
retain: true,
qos: 1
};
return [out, null];
Setting retain: true means any new subscriber immediately receives the last value of every data point, which is how most Unified Namespace consumers expect the tree to behave. The source field keeps a trail back to the original topic, which helps a lot when debugging.
Importable flow
You can import the complete flow with Menu → Import. Paste the function code above into the function node after import, and change the client ID and prefix to your own values.
[
{"id":"b1","type":"mqtt-broker","name":"public broker","broker":"broker.connectmq.com","port":"1883","clientid":"nr-mapper-ab12cd","autoConnect":true,"usetls":false,"protocolVersion":"5","keepalive":"60","cleansession":true},
{"id":"in1","type":"mqtt in","name":"raw devices","topic":"connectmq/demo/ab12cd/raw/#","qos":"1","datatype":"auto-detect","broker":"b1","nl":false,"rap":true,"rh":0,"inputs":0,"x":140,"y":100,"wires":[["fn1"]]},
{"id":"fn1","type":"function","name":"map to ISA-95","func":"return [msg, null];","outputs":2,"x":340,"y":100,"wires":[["out1"],["dbg1"]]},
{"id":"out1","type":"mqtt out","name":"publish ISA-95","topic":"","qos":"","retain":"","broker":"b1","x":560,"y":80,"wires":[]},
{"id":"dbg1","type":"debug","name":"unmapped","active":true,"complete":"true","x":550,"y":140,"wires":[]}
]
The mqtt out node leaves qos and retain empty so the values set in the function node are used.
Testing the Mapping with mosquitto
Open a terminal and watch the structured side of the tree:
mosquitto_sub -h broker.connectmq.com -p 1883 -i sub-ab12cd -v -t "connectmq/demo/ab12cd/izmir/#"
In a second terminal, simulate devices on the raw side:
mosquitto_pub -h broker.connectmq.com -p 1883 -i pub-ab12cd -t "connectmq/demo/ab12cd/raw/th-0042/temp" -m "23.7"
mosquitto_pub -h broker.connectmq.com -p 1883 -i pub-ab12cd -t "connectmq/demo/ab12cd/raw/meter7/kw" -m '{"value": 4.2}'
mosquitto_pub -h broker.connectmq.com -p 1883 -i pub-ab12cd -t "connectmq/demo/ab12cd/raw/unknown-1/temp" -m "19"
The first two messages should appear under izmir/packaging/line2/filler1/temperature and izmir/utilities/main/meter7/power. The third should show up in the Node-RED debug sidebar as unmapped.
Avoiding Loops and Other Pitfalls
The most common mistake in remapping flows is subscribing to a wildcard that also matches the output. If the mqtt in node listens on connectmq/demo/ab12cd/# and the flow publishes back under the same prefix, every republished message is received again, remapped again and eventually floods the broker. Keep raw and structured data in separate branches of the tree, and subscribe only to the raw branch.
With MQTT 5 you can also enable the no local option on the mqtt in node, so the client never receives messages it published itself. That is a safety net, not a substitute for good topic design, because a second Node-RED instance would still see the messages.
Other pitfalls worth checking:
| Symptom | Likely cause | Fix |
|---|---|---|
| Nothing republished | Function returns null on both outputs |
Check the debug output and the parts.length check |
Output topic contains undefined |
Device in table but missing a level | Validate each table entry has all four levels |
| Old values reappear after a rename | Retained messages on the old topic | Publish an empty retained payload to the old topic to clear it |
| Strings instead of numbers downstream | Raw payload had units such as 23.7C |
Strip units in the function node before Number() |
| Disconnects on the public broker | More than 10 messages per second per client | Throttle with a delay node or use your own broker |
Moving the Flow to Production
The public broker is fine for experiments, but production data belongs on a private broker with credentials and TLS. Create a broker at ConnectMQ, copy the generated username, password and client ID from the portal, and change the broker config node to:
- Server
broker.connectmq.com(or your broker host from the portal), port8883, Use TLS enabled - Client ID
YOUR_CLIENT_ID, usernameYOUR_USERNAME, passwordYOUR_PASSWORD - Protocol MQTT V5
The broker certificate is issued by Let's Encrypt, so the default trust store in Node-RED's Node.js runtime validates it without uploading a CA file. Our Node-RED MQTT over TLS guide walks through the TLS settings step by step.
Once the structured topics are flowing, the ConnectMQ portal detects the ISA-95 shaped namespace and shows your devices grouped by site, area, line and machine, and the live topic explorer lets you check the tree without opening a separate client. If some of your sources already speak Sparkplug B, you may not need Node-RED for them at all: the broker can decode Sparkplug B and republish it into ISA-95 topics, so Node-RED only has to handle the plain, flat topics. For PLC sources, the Node-RED Modbus guide shows how to read registers and feed them into the same mapping flow.
Because a managed broker handles the uptime, certificates and connection limits, the mapping flow becomes the only moving part you maintain. That is a large part of why teams move from a self-hosted Mosquitto box to a managed MQTT broker once the namespace grows.
Scaling the Mapping Table
When the number of devices grows past what you want to edit inside a function node, move the table out:
- Retained configuration topic: publish the mapping as a retained JSON message, for example to
config/topic-map, subscribe to it in a separate flow and store it inglobal.set("topicMap", msg.payload). The mapping function reads it withglobal.get("topicMap"). Updates take effect without a redeploy. - File or database: read a CSV or JSON file at startup with a file in node, or query a small table, which suits teams that already manage an asset register.
- Pattern rules: if device IDs encode their location, such as
iz-pk-l2-filler1-temp, a split-based rule can replace most of the table, with a small table for exceptions.
Whatever you choose, keep the unmapped output wired to something visible. New devices appear quietly, and an unmapped warning is often the only sign that a gateway has been replaced or renamed.
